Main antenna:Internal antenna & External antenna inferface
Receive diversity: Internal antenna
Battery: 2000mAh
Description:
Dimensions: 107.5*63.8*14.8mm
Weight: about 102g
Battery: 2000mAh
AC adapter:5V/1.0A
Wireless chipset supplier: Wisefone
Routing and WiFi chipset supplier: Realtek
Wireless chipset model: ZX297520V3E
Processor: Cortex-A53,cortex-A53 up to 624MHz
Routing and WiFi chipset model: WiFi Realtek 8192ES(2*2)
Routing and WiFi processor info: CMOS MAC,Baseband MIMO PHY,and RF insingle chip for 802.11b/g/n compatible WLAN
USIM/SIM slot:3FF SIM card
Memory(SDRAM/NAND):64MBytes/128MBytes
USB version:USB2.0 High speed
Inferface：USB and WiFi
Standbuy time:250hours
Working time:5 hours
Maximum power consumption:4W
LED indicator:4 LED indicators Battery indicator, WiFi indicator,SMS indicator,Nerwork indicator
Chipset:ZX234220A1
Main antenna:Internal antenna & External antenna inferface
Receive diversity: Internal antenna
GSM band:Band 2/3/5/8
UMTS band:Band 1/2/5/8
LTE band:FDD-LTE B1/2/3/5/7/8/20/28 TDD-LTE:B38(41)/40
MIMO for wireless: LTE 4*2 MIMO
WiFi Band: 2400MHz~2483.5MHz
